Resistor network - Resistor network Y, 47Ù, SMD, 1206, No.of resistors 4, 63mW, ±5%

Prod code: 25801

DR1206-47R-4/8 PDF

DR1206-47R-4/8

Price:  0.02 €
VAT:  0.01 €
Final price with tax:  0.03 €
Amount:
Usually shipped within 1 business day.
Specifications
Manufacturer ROYAL OHM
Resistor network type Y
Resistance 47Ω
Mounting SMD
Case 1206
Number of resistors 4
Power 63mW
Resistor features terminals of all resistors are separated
Tolerance ±5%
Terminal pitch 0.8mm
Operating temperature 55...125°C
Body dimensions 3.2 x 1.6 x 0.5mm
Max. operating voltage 50V
Temperature coefficient 400ppm/°C
Max. overload voltage 100V
Min. insulation resistance 1GΩ
Dimensions  VIEW

Availability: On stock
