Pwr sup.unit pulse Outputs 3 Usup 90V AC÷264V AC Uout 5V - 18.47 EUR : acdcshop.gr


Open Frame Power Supply - Pwr sup.unit pulse Outputs 3 Usup 90V AC÷264V AC Uout 5V	Prod code: 10737
PDF	PT-65C

Click to enlarge Pwr sup.unit pulse Outputs 3 Usup 90V AC÷264V AC Uout 5V

Price:	18.47 €
VAT:	4.43 €
Final price with tax:	22.90 €
Amount:
Usually shipped within 2-3 business days.

Specifications
Manufacturer	MEAN WELL
Pwr sup. unit type	switched-mode
Power	65W
Supply voltage	120...370V DC, 90...264V AC
Number of outputs	3
Output voltage	5V DC
Output voltage 2	15V DC
Output voltage 3	15V DC
Output current	5.5A
Output current 2	2A
Output current 3	0.5A
Kind of power supply	open
Power supply/converter features	rated parameters obtained at full load
Mounting	for building in
Operating temperature	10...60°C
Protection	overload, voltage growth, short-circuit
Weight	250g
Body dimensions	127 x 76.2 x 42mm
Efficiency	77%
Series	PT-65
Electrical connection	plug with 3,96mm pitch
Dimensions	VIEW

Availability: With order
