Din rail power supply - Pwr sup.unit pulse, 480W, 48VDC, 10A, 90÷264VAC, 127÷370VDC

Prod code: 16029

SDR-480P-48 PDF

SDR-480P-48

Price:  153.50 €
VAT:  36.84 €
Final price with tax:  190.34 €
Amount:
Usually shipped within 2-3 business days.
Specifications
Manufacturer MEAN WELL
Pwr sup. unit type switched-mode
Power 480W
Output voltage 48V DC, 48...55V DC
Output current 10A
Supply voltage 90...264V AC, 127...370V DC
Electrical connection terminal block
Mounting DIN
Body dimensions 85.5 x 125.2 x 128.5mm
Weight 1.6kg
Number of outputs 1
Operating temperature 25...70°C
Protection overload, overheating, overvoltage, short-circuit
Efficiency 94%
Additional functions active PFC, parallel function, output voltage correctness indication (NO contact)
Power supply/converter features rated parameters obtained at full load
Series SDR-480P
Case type 984A
Dimensions  VIEW

Availability: With order
