power supplies - Pwr sup.unit pulse, 20W, 15VDC, 1.34A, 85÷264VAC, 120÷370VDC, 190g

Prod code: 212

MDR-20-15 PDF

MDR-20-15

Price:  15.04 €
VAT:  3.61 €
Final price with tax:  18.64 €
Amount:
Usually shipped within 2-3 business days.
Specifications
Manufacturer MEAN WELL
Pwr sup. unit type switched-mode
Power 20W
Output voltage 15V DC
Output current 1.34A
Supply voltage 85...264V AC, 120...370V DC
Electrical connection terminal block
Mounting DIN
Body dimensions 22.5 x 90 x 100mm
Weight 190g
Number of outputs 1
Operating temperature 20...70°C
Protection overload, overheating, overvoltage, short-circuit
Efficiency 81%
Additional functions output voltage correctness indication (NO contact)
Power supply/converter features rated parameters obtained at full load
Dimensions  VIEW

Availability: With order
