Pwr sup.unit buffer, 59.34W, 127÷370VDC, 90÷264VAC, Outputs 2 - 21.35 EUR : acdcshop.gr


Open Frame power supply - Pwr sup.unit buffer, 59.34W, 127÷370VDC, 90÷264VAC, Outputs 2	Prod code: 20034
PDF	PSC-60B

Click to enlarge Pwr sup.unit buffer, 59.34W, 127÷370VDC, 90÷264VAC, Outputs 2

Price:	21.35 €
VAT:	5.12 €
Final price with tax:	26.47 €
Amount:
Usually shipped within 1 business day.Usually shipped within 1 business day.

Specifications
Manufacturer	MEAN WELL
Pwr sup. unit type	buffer
Power	59.34W
Supply voltage	90...264V AC, 127...370V DC
Number of outputs	2
Output voltage	27.6V DC
Output voltage 2	27.6V DC
Output current	1.4A
Output current 2	0.75A
Kind of power supply	open
Power supply/converter features	rated parameters obtained at full load
Operating temperature	20...70°C
Efficiency	84%
Mounting	for building in
Protection	battery polarity, battery low protection, overload, overvoltage, short-circuit
Weight	130g
Body dimensions	101.6 x 50.8 x 29mm
Series	PSC-60
Additional functions	UPS, battery tester
Dimensions	VIEW

Availability: On stock
